[新品] ZP21W型旋转式压片机 |
 |
 供应商参考报价：面议 |
|
|
|
| 联系人： |
|
蒋为东 |
| 所在城市： |
|
江苏省 兴化市 |
| 详细地址： |
|
兴化市沈伦工业园区 |
|
|
|
|
|
 |
 |
| 在手机上查看本产品 |
扫一扫访问微商铺 |
|
|
|
|
| 详细信息 |
|
 |
技术参数：
|
型号
|
ZPW21A
|
|
总模数(付)
|
21
|
|
***大压片压力(KN 千牛)
|
80
|
|
***大压片直径(mm)
|
20
|
|
***大充填深度(mm)
|
18
|
|
***大片剂厚度(mm)
|
9
|
|
转盘转速(r/min转/分)
|
12—36
|
|
生产能力(pc/h 片/时)
|
15000—45000
|
|
电动机功率(kw)
|
3kw千瓦 1440r/min转/分 380/50 V/Hz伏/赫
|
|
外形尺寸(mm)
|
900×840×1640
|
|
主机重量(kg)
|
1200
|
Product features：
Thiw machine is designed for various granular materials compressed into flake, its biggest advantage is in addition to the circular piece can suppress all sorts of geometry shapes of special-shaped tablets, double slice, circular piece and double-sided lettering pieces. Turntable can pack 21 pay on stamping, rotate week adjustabie type can be pressure 21 pieces. Rotary speed and pressure for depth of the filling material and thickness of the tablets can be adjusted, still can choose piece look samples. Presser pressure is set by hydraulic system, with pressure gauge shows. Hydraulic system equipped with overload protection device, within the pressure can automatic stop, overload, mechanical damage to avoid with separate suck at random, it can suck the height powder produced when machine of dust, avoid dust bond jams, and recyclable materials to use again. This machine is our factory eighty
Technical parameters:
|
Type
|
ZPW21A
|
|
Total module (pay)
|
21
|
|
Maximum differential pressure (KN thousand pieces cattle)
|
80
|
|
Maximum presser diameter (mm)
|
20
|
|
Maximum filling depth (mm).
|
18
|
|
Maximum tablet thickness (mm)
|
9
|
|
Wheel speed (r/min R.P.M.)
|
12-36
|
|
Production capacity (PC/h piece /)
|
15,000-45,000
|
|
Motor power 3kw kilowatts (kw)
|
1440r/min R.P.M. 380/50 V/Hz volts/Hector
|
|
Shape dimension (mm)
|
900 x 840 x1640
|
|
Host weight (kg)
|
1200
|
|
 |
|
|
|
 |
